Separate line itemEM · constⒶNTHigh power
EM60-GMB/170DC LED Emergency Driver
60 W emergency driver for high-bay LED arrays.
Runs a 170 V DC high-bay array at 60 W for 90 minutes when the AC fails, and holds that output to the end instead of dimming as the battery drains. Mounts inside the fixture. Universal 100–347 V AC input: one catalog number for every building voltage. Takes host fixtures up to 600 W.
Emergency60W
Runtime90min
Input100–347V AC
Output170V DC
Host fixtures
lamparⒶRCHHigh bay & strip
Constant Power
Auto Transfer
Test Switch
100–347 V AC
Factory or Field
Damp Location
5-Yr Warranty
UL 924Listed
CSA C22.2 No. 141Listed
CEC Title 20Compliant
ChargingGMB · 170 V DC
EM60-GMB/170DCEmergency LED driver · UL 924
Input100–347 V AC
Output170 V DC
Power60 W
Runtime90 min
Downloads
Documentation & Resources
Specifications
Model Specifications
Emergency output60 W constant power · 90 minOutput holds for the full 90 minutes
Output170 V DC · 460 mA maxHost fixture up to 600 W
Input100–347 V AC · 50/60 Hz200 mA max · 15 W max · PF > 0.50
BatteryLithiumRecharge 24 h · charge current 0–250 mA
Dimensions14.57″ L × 3.03″ W × 1.84″ HMounting centers 13.78″ · one integrated case
LeadsUL 2464 · 24 AWG · 300 V · 80 °C21.65″ leads
MountingInside the fixtureFactory or field installation
Operating temp32 °F to 122 °FStorage 158 °F max
LocationDry or dampStandard unit: on request
ListingsUL 924 · CSA C22.2 No. 141CEC Title 20
Warranty5-year limitedDriver and battery
Engineering
When the power fails.
What it does when the power fails, how you test it, and how it goes in.
Holds 60 W for the full 90 minutes. The output does not taper as the battery drains.Rated output · 90 min
Senses AC loss on the unswitched hot and takes the LED array. When AC returns it hands the array back and recharges.No switch to throw
Red light on: charging. Off: running on battery. Use the switch for the monthly functional test.Remote test switches below
Cuts out on overcharge, over-discharge and short circuit.Recharge 24 h
100–347 V AC, 50/60 Hz. One catalog number for 120, 208, 240, 277 and 347 V circuits.One SKU per job
UL listed for installation at the factory or in the field. Same branch circuit as the AC LED driver.Install rule on the data sheet
EM60-GMB/170DC · Constant power
Performance
Emergency Performance
Rated emergency outputUL 924 minimum runtime
Rated output
60 W
Constant power
Runtime
90 min
UL 924 listed
Recharge
24 h
To full, after a discharge
Max host fixture
600 W
Per data sheet
Emergency lumens · estimate
60 W × 140 lm/W. An estimate, not a test result. Set the slider to your host fixture’s efficacy.
NFPA 101 §7.9.21 fc average, 0.1 fc minimum along the egress path.Allowed to fall to 0.6 fc average and 0.06 fc minimum by the end of 90 minutes. Lay the job out against the host fixture’s emergency photometrics.
Accessories
Test Switches & Mounts
Indoor
constⒶNT · Remote test
Red Button · Separate Green LED
EM-TB/03BTest button and charge light read as two separate signals.
Separate line itemIndoor
constⒶNT · Remote test
Green Ribbon LED Test Switch
EM-TB/21BLong ribbon indicator, readable from the far end of an aisle.
Separate line itemDry location
constⒶNT · Remote test
Red & Green LED Test Switch
EM-TB/29BBoth indicators in one face.
Separate line itemWet location · IP65
constⒶNT · Remote test
Red LED Test Switch · Wet Location
EM-TB/09BSealed face for canopies, wash-down and outdoor hosts.
Separate line itemRemote test switches fit constⒶNT EM drivers. Put them where the monthly test can be reached without opening the fixture. Switch faces shown are illustrations.
Configurator
Build Your GMB Driver.
Optional
Remote test switch—
Ordered as its own line
Your catalog number
Your Catalog Number
Catalog number
EM60-GMB/170DC
1 ×EM60-GMB/170DC60 W emergency driver
→UL 924 · CSA C22.2 No. 141 · CEC Title 20Listings for this catalog number
→Lead time for this catalog number
Family
constⒶNT EM Drivers
Seventeen drivers, sorted by emergency output. Match the output to the host fixture’s array voltage and the egress layout.
Low power7–8 W · 6 drivers
8W
EM08-AMB/48DC
25–48 V DC · Class 2
Auxiliary-mount bracket · Factory or field
Mid power15–25 W · 7 drivers
15W
EM15-HMB/170DC
170 V DC
Surface mount · J-box kits · Factory or field
High power30–60 W · 4 drivers
Specify
Put it on the submittal.
Data sheet, wiring diagram and listings in one package, ready for the AHJ.
UL 924Listed
90 minRuntime
5 yrLimited warranty
