EM30-UMB/170DC LED Emergency Driver
30 W external emergency driver for 170 V DC high-bay arrays.
Runs a 170 V DC high-bay array at 30 W for 90 minutes when the AC fails, and holds that output to the end instead of dimming as the battery drains. An external box that mounts on the side of the fixture, added in the field. Universal 100–347 V AC input. Takes host fixtures up to 300 W.
Emergency30W
Runtime90min
Input100–347V AC
Output170V DC
Host fixtures
lamparⒶRCHHigh bay & strip
Constant Power
Auto Transfer
Test Switch
100–347 V AC
Field Install
Damp Location
5-Yr Warranty
UL 924Listed
CSA C22.2 No. 141Listed
CEC Title 20Compliant
ChargingUMB · 170 V DC
EM30-UMB/170DCEmergency LED driver · UL 924
Input100–347 V AC
Output170 V DC
Power30 W
Runtime90 min
Downloads
Documentation & Resources
Specifications
Model Specifications
Emergency output30 W constant power · 90 minOutput holds for the full 90 minutes
Output170 V DC · 175 V max170 mA max · host fixture up to 300 W
Input100–347 V AC · 50/60 Hz200 mA max · 15 W max · PF > 0.50
BatteryLithiumRecharge 24 h · charge current 300 mA
Dimensions11.00″ L × 4.26″ W × 4.26″ HMounting centers 5.61″ · external box
LeadsUL 2464 · 24 AWG · 300 V · 80 °C21.65″ leads
MountingExternal, fixture sideField installation
Operating temp32 °F to 122 °FStorage 158 °F max
LocationDry or dampStandard unit: on request
ListingsUL 924 · CSA C22.2 No. 141CEC Title 20
Warranty5-year limitedDriver and battery
Engineering
When the power fails.
What it does when the power fails, how you test it, and how it goes in.
Holds 30 W for the full 90 minutes. The output does not taper as the battery drains.Rated output · 90 min
Senses AC loss on the unswitched hot and takes the LED array. When AC returns it hands the array back and recharges.No switch to throw
Red light on: charging. Off: running on battery. Use the switch for the monthly functional test.Remote test switches below
Cuts out on overcharge, over-discharge and short circuit.Recharge 24 h
100–347 V AC, 50/60 Hz. One catalog number for 120, 208, 240, 277 and 347 V circuits.One SKU per job
UL listed for field installation. Mounts outside the fixture, on the same branch circuit as the AC LED driver.Install rule on the data sheet
